Hammerwinch HMW 4.3 PHT-EN
| Produkt nr: | AD740 |
| Pris eks. mva: | NOK 21 400,00 |
| Pris (inkl. mva.): | NOK 26 750,00 |
| Tilgjengelighet: | På lager |
Hammerwinch 4,3 tonn
| Max. pulling capacity (kg/Ibs): | 4300 kg (9477 lbs) |
| Max. rope length (m/ft): | 48 m (157 ft) |
| Max. rope length for EN (m/ft): | 36 m (118 ft) |
| Recommended wire rope (mm/in): | 11 mm (4/9”) 1960 Mpa |
| Hydromotor (cc/in³): | 315 cc (19 in³) |
| Max. pump flow (L/min-g/min): | 60 L/min (15.8 g/min) |
| Gear ratio: | 5,6:1 |
| Oil types and capactiy: | 85 W 90 - 0,75 L |
| Max. working pressure (bar/psi): | 120 bar (1740 psi) |
| Winch (kg/Ibs): | 54 kg (119 Ibs) |
| Roller Fairlead (kg/lbs): | 6 kg (13,22 lbs) |
| Cable Tensioner (kg/Ibs): | 2,5 kg (5,51 lbs) |
